Basic electr. Amps. Start Amps Watts No of Wires Amp. Fuse
Page 03
SPECIFICATIONS (CONT'D)
Electr. power cons.
Kwh per 24 Hrs
230/50/1 3.5 18 550 10 3 x 1 m/m 10
2
Cubes per harvest: 32 medium
* At 15°C (60°F) water temperature
AC 105 - CUBER MACHINE SPECIFICATION
Model Cond. Finish Comp. HP
Ice bin cap. Water requirem
Kgs. LTx24 HR
AC 105 AS Air S/Steel 180*
3/8 18
AC 105 WS Water S/Steel 530*
FRONT VIEW
HEIGHT (without legs) 813 mm.
HEIGHT (with legs) 950 mm.
WIDTH 535 mm.
DEPTH 534 mm.
WEIGHT 44 Kgs.
