Page 6
12. Has the owner been given the name and the
phone number of the authorized SCOTSMAN
Service Agency serving him?
11. Has the water supply pressure been
checked to ensure a water pressure of at least 1
bar (14 psi).
WARNING. This icemaker is not designed for outdoor installation and will not function
in ambient temperatures below 10°C (50°F) or above 40°C (100°F).
This icemaker will malfunction with water temperatures below 5°C (40°F) or above
40°C (100°F).
1. Hand shut-off valve
2. Water filter
3. Water supply line (flexible hose)
4. 3/4" male fitting
5. Vented drain
6. Open trapped vented drain
7. Drain fitting
8. Main switch
9. Power line
G. INSTALLATION PRACTICE
