Page 15
Page 15
THE PARTS ILLUSTRATIONS AND PARTS LIST
Pos. Part. N. Description
4 630070.04 Terminal board
6 620264.10 Evaporator thermostat
7 660321.01 Panel
8 620263.00 Bin control
CONTROL PANEL ASSY
±
