Scotsman AFE424A-1 - Specifications

Specifications
The unit is equipped with an electrical power cord,
but should only be plugged into a circuit dedicated
to the ice machine.
AFE424
April 2010
Page 2
14.25
IN
Model Number Dimensions
(w/o) legs
HxWxD
Basic
Electrical
Ice
Type
Condenser
Type
Typical
Amps
Maximum
Fuse
Refrigerant
Charge,
R-134a.
AFE424A-1 33 x 24
1
4
x 24 115/60/1 Flake Air 9 15 15 oz
AFE424W-1 same same same same same same 9 oz
AFE424A-6 33 x 24
1
4
x 24 230/50/1 Flake Air 9 15 15 oz
A scoop and legs (6") are included.
SERIAL
NUMBER
PLATE
The nameplate is located
on the back panel.
A serial number plate is
located behind the right
grill, in front of the control
box, on the base.
