Operational Characteristics: CME506
Cycle Times (minutes):
System Pressures (PSIG):
A -D Series Refrigerant Charge, R-404A
•
Air cooled: 32 ounces
•
Water cooled: 20 ounces
E Series Refrigerant Charge, R-404A
•
Air cooled: 23 ounces
•
Water cooled: 14 ounces
F Series Refrigerant Charge, R-404A
•
Air Cooled: 23 ounces
•
Water Cooled: 13 ounces
Typical Compressor Amps
•
Freeze: 10 - 11
•
Harvest:11 - 12
Typical Harvest Ice Weight
•
6.5 - 7 lb.
Water Cooled:
•
Discharge Pressure: 245 PSIG
•
Hi Pressure Cuts Out at: 450 PSIG
Fan Control Switch - for units so equipped:
•
CutIn:240PSIG+-20PSIG
•
Cut Out: 190 PSIG+-10PSIG
CME256, 506, 656, 806: AutoIQ™ Cubers
July 2002
Page 28
Air Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Freeze 18 - 20 22 - 24
Harvest 2 1:30
Water Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Freeze 20 - 22 22 - 24
Harvest 1.5 - 2.5 1.5 - 2
Air Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Suction: End of Freeze 35- 37 35 - 37
Suction: Peak in Harvest 115 - 120 120 - 125
Discharge: 5 minutes into Freeze 240 - 260 240 - 260
Discharge: Minimum in Harvest 155- 165 165 - 175
Water Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Suction: End of Freeze 30 - 34 30 - 34
Suction: Peak in Harvest 75 - 85 80 - 90
Discharge: 245 PSIG 245 PSIG
Discharge: Minimum in Harvest 150 - 160 175 - 185
