Scotsman CME256 - Operational Characteristics: CME806

CME256, 506, 656, 806: AutoIQ™ Cubers
June 2002
Page 30
Operational Characteristics: CME806
Cycle Times (minutes)
System Pressures
A - E Series Refrigerant Charge, R-404A
•
Air cooled: 33 ounces
•
Water cooled: 24 ounces
F Series Refrigerant Charge, R-404A
•
Air cooled: 33 ounces
•
Water cooled: 26 ounces
Typical Compressor Amps
•
Freeze: single phase = 13
•
Harvest: single phase = 14
Typical Harvest Ice Weight
•
6.5 - 7 lb.
Water Cooled:
•
Discharge Pressure: 240 - 245 PSIG
•
Hi Pressure Cuts Out at: 450 PSIG
Fan Control Switch - for units so equipped:
•
CutIn:240PSIG+-20PSIG
•
Cut Out: 190 PSIG+-10PSIG
Air Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Freeze 9 - 11 12 - 14
Harvest 1:45 1:15
Water Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Freeze 10 - 12 12 - 13
Harvest 1:45 1:15
Air Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Suction: End of Freeze 20 - 21 25 - 27
Suction: Peak in Harvest 89 - 91 115 - 125
Discharge: 5 minutes into Freeze 210 - 220 280 - 290
Discharge: Minimum in Harvest 155 205
Water Cooled 70
o
F. indoor air, 50
o
F. water 90
o
F. indoor air, 70
o
F. water
Suction: End of Freeze 24 - 26 24 - 26
Suction: Peak in Harvest 85 - 95 90 - 95
Discharge: 240 PSIG 240 PSIG
Discharge: Minimum in Harvest 155 165
