Scotsman CU0415 - Pre-Installation Requirements

July 2013
Page 3
User Manual for Models CU0415, CU0715 and CU0920
Pre-Installation
This appliance is intended to be used in commercial
applications including:
• Restaurant kitchens
• Bars
• Hotels
Dimensions and Electrical:
Location:
Theunitcanbebuiltintoacabinetastheairow
is in and out the front. The front of the machine
must not be blocked. Certain maintenance or
repairprocedureswillrequireremovalofthetop,
backandsidepanels,soplanaheadforserviceand
maintenance needs.
Spacing:
Noadditionalspacingisrequiredatthetoporsides.
However,suggestedminimumsideclearancefor
installation is 1/8 inch or 3 mm and suggested
minimum top clearance is 1/4 inch or 7 mm.
Allow4inches(100mm)minimumspaceattheback
fortheutilityconnections.Donotblocklouversatthe
front of the cabinet.
Unpacking and setup
Removeallshippingandpackingmaterialsthatmay
be in the ice storage bin.
Theunitcanbeinstalledwithorwithoutlegs.The
cabinetisequippedwithsmallbumpersonthebase
toallowplacementwithoutlegs.Anoptionaloor
mountingkitisalsoavailabletollthegapbetween
themachineandoorifnotusinglegs.Ifusinglegs,
carefully tip the machine and install the legs by
screwingthemintothelegsocketsinthebottomof
the machine. For reference, the thread size is 5/8 –
11.Ifthemachinehasbeentippedontoitssideor
backallow1hourbeforestartingtheunitfortheoilin
the refrigeration system to return to the compressor.
Placethemachineinitsintendedlocationandlevelit
fronttobackandlefttoright.Ifusinglegs,adjusttheir
feetinandouttolevelthecabinet.
Iflegsarenotusedthebottomedgesofthecabinet
mustbesealedtotheoor.
Ifbuiltintoacabinet,theadjacentcabinetwallswill
providethemeansforcontainment.Thereareno
means for attachment to the cabinet.
Besuretoremovetheplasticcoveringtheexteriorpanels,
ifleftonitwillbemuchhardertoremovelater.
Model Electrical
(volts/Hz/Phase
Width
(in/cm)
Depth
(in/cm)
Height(w/olegs)
(in/cm)
Total Load
Amps
CU0415MA-1A 115/60/1 15 / 38 23.7 / 60.3 31.94 / 81.1 8
CU0715MA-1A 115/60/1 15 / 38 23.7 / 60.3 31.94 / 81.1 8
CU0920MA-1A 115/60/1 20 / 51 23.7 / 60.3 31.94 / 81.1 8
AirIN
Air OUT
