Scotsman CU0715 - Cabinet Layout, CU0920

August 2013
Page 5
Service Manual for Models CU0415, CU0715 and CU0920
Cabinet Layout, CU0920
95.4cm
37.56in
42.5cm
16.75in
81.1cm
31.94in
AIR
INLET
AIR
OUTLET
48.3cm
19.00in
68.9cm
27.13in
15.2cm
6.00in
10.2cm
4.00in
MINIMUM
UTILITY
CLEARENCE
DRAIN
3/4" FPT
POWER CORD
50.8cm
20.00in
60.1cm
23.67in
POWER CORD
POTABLE
WATER INLET
1/4" OD. PLASTIC
TUBING (5ft)
DRAIN
3/4" FPT
32cm
12.60in
14.6cm
5.75in
7cm
2.75in
8.2cm
3.23in
5.1cm
2.00in
POTABLE
WATER INLET
1/4" OD. PLASTIC
TUBING (5ft)
