TABLE OF
CONTENTS
Foreword page 2
Table of contents 3
Specifications 4-9
Section I GENERAL INFORMATION
General 10
Application area 10
Condensing unit 10
Control devices 11
Location considerations 12
Refrigerant lines 12
Hydraulic circuit 12
Ice storage room 12-14
Unit layout 15
Section II INSTALLATION
Unpacking and inspection 16
Location and levelling 16
Refrigerant piping connections 16
Water piping connections 17
Water and refrigerant circuit 17
Electrical connections 18
Installation practice 19
Mar Split in multiple installation 20
Typical non-code commercial installation 20
Section III TESTING
Complete system leak test 21
Complete system evacuation 21
Complete system charging 21
Start-up & Check-out 21
Operational check-out 21-23
Section IV PRINCIPLE OF OPERATION - HOW IT WORKS
ICE maker 24
MAR Split electrical/refrigeration 25-26
Section V ADJUSTMENT & REMOVAL & REPLACEMENT
PROCEDURES
MAR Split 27-28
Section VI MAINTENANCE & CLEANING INSTRUCTIONS 29-32
Section VII SERVICE DIAGNOSIS 33-34
Section VIII WIRING DIAGRAMS 35
