FOR THE INSTALLER
INTRODUCTION
These instructions provide the specifications and
the step-by-step procedures for the installation,
start up and operation for the SCOTSMAN
Model MV 12-21-32-50 Modular Cubers.
The Models MV 12-21-32-50 Modular Cubers
are quality designed, engineering and
constructed, and are thoroughly tested icemaking
systems, providing the utmost in flexibility to fit
the needs of a particular user.
INSTALLATION NOTE: Allow 15 cm.
minimum space at sides and back for
ventilation and utility connections.
STORAGE BIN
The MV 12 stack on top of Scotsman bin model
B 190; the MV 21-32 stack onto SCOTSMAN bin
model B.390 while the model MV 50 onto bin
B.550.
Refrigerant R 404 A
Charge per nameplate rating.
STANDARD LEGS: Furnished with storage bin.
Four legs screw into mounting sockets on cabinet
base. Provide 16 cm. (6'’) minimum height
including adjustable leveling foot.
Optional Kit Casters for B 190-390 (KRB 390)
and for B 550 (KRB 550) are available on request.
IMPORTANT OPERATING REQUIREMENTS
MINIMUM MAXIMUM
Air Temperature 10°C (50°F) 40°C (100°F)
Water Temperature 5°C (40°F) 35°C (90°F)0
Water Pressures 1 bar gauge 5 bar gauge
Electrical Voltage
Variations Voltage
rating specified
on nameplate -10% +10%
Extended periods of operation exceeding these
limitations constitues misuse under the terms of
Manufacturer’s Limited Warranty, resulting in a
loss of warranty coverage.
