NOTE: RINSING mode consists of:
a) energize the water drain valve and the
water pump for 30 seconds to empty the
reservoir
b) deenergize the water drain valve and the
water pump for 1 minute
c) energize the water pump for 3 minutes.
The above sequence is repeted 7 times so to
be sure to have removed any possible trace
of Ice Machine Cleaner.
6. At the end of the 7th Rinsing cycle the P.C.
Board stops the operation of the machine with
the blinking (slow) of the Yellow LED.
7. Pushing the RESET BUTTON for 6-8
seconds the machine restarts in the freezing
cycle.
8. Replace the evaporator cover deflector and
front panel.
9. Check the next batch of cubes to be sure all
the cleaner is gone (no sour taste).
CAUTION - DO NOT use ice cubes
produced from the cleaning solution. Be
sure none remains in the bin.
10. Pour hot water into the storage bin melt the
cubes, and to also clean the bin drain.
B190 - B390 - B550 - BIN
A
B
C
D
F
G
HI
J
K
L
E
AB CD E FGH I J KL
B 190 560 795 605 895 110 1005 430 65 65 560 110 110
B 390 805 795 600 900 110 1010 600 100 100 620 80 80
B 550 1075 785 550 820 160 980 877 97 97 582 96 96
DIMENSIONS ARE IN MILLIMETERS
