SCOTT CX 100 DP User Manual

LOCATION OF CONTROLS
GB 2
BOX CONTENTS
1. Unit 3. Instruction manual
2. AC power cradle
1 2 3 1
4
5
6 7 8 9 10 11 12 13 14 15 16 17
1 2 3 2 4 5 6
7 8
Unit
1. Speakers (2x)
2. LED AC power indicator via the power cradle
3. LCD display
4. VOLUME +/- buttons
5. MUTE button
6. Clock/Alarm set
7. ALARM MODE button
8. DISPLAY button
9. SLEEP button
10. FM antenna
11. Battery door
12. SNOOZE button
13. MEMO button (preset stations)
14. P+/P- preset buttons
15. BAND button
16. button
17. TUNE/SET +/- button
LCD display
1. Stereo indicator (ST) in FM radio
2. Radio FM/ MW radio mode indicators
3. Time and frequency display
4. SNOOZE mode
5. SLEEP mode
6. MHz/kHz: Unit ofFrequency units in FM/MW
radio mode frequency
7. Buzzer alarm mode ( )
8. Radio alarm mode ( )
CR25-SCOTT-AMFM-ENG.indd 3 12/11/2008 16:41:11

SCOTT CX 100 DP Specifications

Radio

FM tuning range	87.5 – 108 MHz
MW tuning range	522 – 1620 kHz
FM antenna type	telescopic
MW antenna type	built-in ferrite bar

General

output power	2 x 80mW
power consumption	3.5 W
speaker diameter	2 inches
speaker impedance	8 Ohm

Power

AC power input	AC 230V ~ 50Hz
DC power output	DC 4.5V
battery power	DC 4.5V: 3 x 1.5V UM3/ “AA” batteries

Weight and Dimensions

dimensions	80 (H) x 190 (W) x 36 (D) mm
unit weight	0.24 Kg
unit weight with AC power cradle	0.5 Kg
