SCOTT CX 100 DP User Manual

Listen to the radio
1. Press the button to turn on the unit.
2. Press the BAND button to select FM or MW.
3. Hold down the TUNE/SET +/- button for 2 seconds to launch automatic tuning for stations ( up or down ).
Release the button to receive a radio station. For manual ne-tuning, you can press these buttons briey
to adjust the frequency step by step.
FM Stereo
In FM mode, the symbol “ ” is displayed when an FM stereo station is received. You can now enjoy stereo
sound.
Achieve optimum reception
In FM mode, extend and position the FM antenna to achieve optimum reception.
In MW mode, orientate the unit to achieve optimum reception.
Preset radio stations
You can store up to 10 stations each for FM and MW.
Automatically store stations
Hold down the MEMO button for 2 seconds, and the unit will automatically search and store the stations it nds.
Manually store stations
1. Use the TUNE/SET +/- buttons to manually search for a desired station.
Then press the MEMO button to memorize the station you have found.
The station number will ash.
2. Press the P+/P- buttons to select the number you would like to allocate to the station.
3. Press the MEMO button again to conrm the setting.
4. Repeat steps 1 to 3 above to store any other desired stations.
Listen to a preset station
When listening to the radio, press the P+/P- button to select a preset radio station.
RADIO OPERATION
GB 6
CR25-SCOTT-AMFM-ENG.indd 7 12/11/2008 16:41:16

SCOTT CX 100 DP Specifications

Radio

FM tuning range	87.5 – 108 MHz
MW tuning range	522 – 1620 kHz
FM antenna type	telescopic
MW antenna type	built-in ferrite bar

General

output power	2 x 80mW
power consumption	3.5 W
speaker diameter	2 inches
speaker impedance	8 Ohm

Power

AC power input	AC 230V ~ 50Hz
DC power output	DC 4.5V
battery power	DC 4.5V: 3 x 1.5V UM3/ “AA” batteries

Weight and Dimensions

dimensions	80 (H) x 190 (W) x 36 (D) mm
unit weight	0.24 Kg
unit weight with AC power cradle	0.5 Kg
