LOCATION OF CONTROLS
Unit back view
1. Ethernet jack
2. DC IN 5V jack
3. Audio Out jack
Unit front and side views
2 3
1. LCD display
23 4
2. SD/MMC card slot
3. USB port
4. IR (Infra-red) remote
control sensor
Remote control
1. (
) ON/STANDBY button
2. BACK button
3. DOWN
button
4. Preset buttons
5. Repeat/Shuffle
/ button
6. Previous
button
7. VOL +/- buttons
8. OK button
9. UP
button
10. Play/Pause
button
11. Stop
button
12. Next
button
13. RECORD
button
14. Fast backward
button
15. MEM button (memory)
16. MENU button
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
13
17. Mute button 18. Fast forward button
2
3
4 5
6
LCD display
1. Name of current menu
2. Connection status (Wi-Fi or Ethernet)
3. Navigation
4. Volume
5. Clock time
6. Content of the current menu
GB-
3
