GAMBLER
BIKE OWNER’S MANUAL
ADJUSTABLE BB HEIGHT BB STANDARDS
On the Gambler you can adjust the BB height above ground for 10mm between its 2
positions by a geo-chip.
Low position is at a BB offset of +0mm, high position is at +10mm offset.
In order to change the set-up please un-tighten the shockmount bolt with a 6mm allen
key.
“Flip-flop” the “geo-chip” on both sides as shown in the drawing below and tighten the
shock mount bolt again with a maximum tightening torque of 35Nm/ 308in/lbs.
On Gambler you will find 2 different BB options, depending on the model you bought:
1. BB PF 104 with a housing
width of 104mm and an
inner diameter of 41mm
for PressFit bearings
2. Standard threaded BSA
with 83mm housing
width for threaded
assembly bearing sets
ENGLISH

SCOTT Gambler Specifications

General

Intended Use	Downhill
Brakes	Shimano BR-M615 Disc 203mm / SM-RT66 Rotor
Drivetrain	Shimano Deore / Saint
Wheelset	Syncros Revelstoke 1.0, 27.5"
Suspension	203mm Front
Wheels	Syncros Revelstoke 1.0, 27.5"
Seatpost	Syncros FL2.0 / 31.6mm
Stem	Syncros AM 1.0, 50mm
Grips	Syncros Pro DH dual lock-on grips
