16 scott-sports.com 17
GAMBLER
BIKE OWNER’S MANUAL
FRONT FORK SET-UP/
CHANGE OF FRONT FORK
For the set up of the front fork please use the fork specific manual attached to the bike.
We recommend using front forks with a travel between 180 and 200 mm (568mm fork
length), as this will not influence the geometry and alter handling of the bike.
PIVOT MAINTENANCE
The pivots and bearings on SCOTT Gambler are extremely easy to maintain.
An external treatment with a grease spray after every bike wash is all you have to do.
We do not recommend heavy grease sprays since these will leave a film on the parts
which is difficult to remove. We recommend the same for the chain also.
If you have to change the bearings you can order them included in a service kit
229705
at your local SCOTT dealer or buy them with international parts number as shown
above in the specs list in a hardware store.
FRONT FORK BUMPER
In order to avoid damages on the frame caused by the fork stanchions hitting
the downtube in case of a crash the Gambler shows rivets on the front end of the
downtube to assemble bumpers.
The bumpers can be replaced if needed. You can order them via the SCOTT
distribution with article number:
229715 frame fork bumper Gambler
In order to replace them please use a 4mm allen key for the M5 bolt and please respect
the maximum tightening torque of 5Nm/44in/lbs.
ENGLISH
