Page25of36
P/N 595225-01 Rev C 4/12
LOW PRESSURE AIR SUPPLY USE
CONTINUED ON NEXT PAGE...
CONNECTING TO THE EBSS (BUDDY BREATHER) HOSE
ON AN AIR-PAK SCBA:
1. Two kinds of EBSS (BUDDY BREATHER) Hose may be encountered:
•asinglefemalequickdisconnect
OR
•adualmale/femalequickdisconnect
2. If the EBSS on the respirator user’s SCBA is a single female quick discon-
nect, attach the male quick disconnect coupling on the RIT-PAK III portable
air supply low pressure dual manifold to the EBSS hose on the respirator
user’s AIR-PAK. The female coupling on the EBSS hose may be either the
Pull-back Sleeve or the Notched Sleeve type of coupling. After connection to
EBSS hose coupling with the Notched Sleeve coupling, make sure the sleeve
isrotated1/4to1/2turnsonotchdoesnotlineupwithrivethead.Testfor
proper engagement by tugging on the couplings.
3. If the EBSS on the respirator user’s SCBA is a dual male/female quick discon-
nect, attach the male quick disconnect coupling on the RIT-PAK III portable air
supply low pressure dual manifold to the female coupling on the dual EBSS
hose on the respirator user’s AIR-PAK. The female coupling will be the Pull-
back Sleeve type of coupling. Test for proper engagement by tugging on the
couplings.
4. Secure the Low pressure dual manifold assembly to the respirator user’s
person while transporting.
To Next Page
