SCOTT SCALE 965 User Manual

2023 SCALE | ENGLISH 5
|
SCALE
It is important to install the headset correctly
depending on the set up required. There are
two types of headset cups.
0° & 0.6° ( 64° & 65°) These can be indentified
from the stamp on the inner surface of the
headset cup
The headset is available in two options:
288251 SYN HEADSET ZS56/28.6-ZS56/40 MTB
290060 SCO HEADSET CUP KIT SPARK 22
Do not use a standard headset tool
to remove these plastic headset
cups.
SCALE
HEADSET ADJUSTMENT
Slacker
Steeper

SCOTT SCALE 965 Specifications

General

Seat	Syncros Belcarra Regular 2.5
Spokes	Stainless Black 15G / 1.8mm
Frame	Scale Alloy 6061 Custom Butted Tubing
Fork	RockShox Judy Silver TK Solo Air
Brakes	Shimano MT200 Disc
Rotor	Shimano RT-10, 180/160mm
Handlebar	Syncros 3.0
H'stem	Syncros 3.0
Seatpost	Syncros 3.0
Headset	Syncros OE Press Fit / Tapered 1.5" - 1 1/8"
Rims	Syncros X-25
Front Tire	2.25"
Rear Tire	2.25"
