MECHANICS HINT
The outer housing of the cables can also be fixed on the bottle cage with cable fixers,
the two brackets below the cage are not needed anymore..
ADJUSTMENT OF SEATPOST-HEIGHT
IMPORTANT:
The seatpost has to be inserted into the seattube at a minimum of 100mm.
Never use another seatpost diameter than 34.9mm on carbon frames or 31.6mm on
alloy frames or try to use a shim/reducer between seatpost and frame.
REPLACEABLE DROPOUT
On Spark bikes you can replace the rear derailleur hanger.
In case the replaceable hanger is damaged by a crash or accident you can order at
your local Scott dealer the replacement part with Scott article number 206473
FRONT FORK SET-UP /
CHANGE OF FRONT FORK
For the set up of the front fork please use the fork specific manual attached to the bike.
We recommend using front forks with a travel of 100 - 120mm, as this will not influence
the geometry and alter handling of the bike.
PIVOT MAINTENANCE
The pivot and bearings on SCOTT Spark are extremely easy to maintain.
An external treatment with a grease spray after every bike wash is all you have to do.
We do not recommend heavy grease sprays since these will leave a film on the parts
which is difficult to remove. We recommend the same for the chain also.
If you have to change the bearings you can order them included in a service kit at your
local SCOTT dealer or buy them with international parts number as shown above in the
specs list in a hardware store.
In case of a change of the bearings or of the rear swingarm you should contact your
local SCOTT dealer as you need special tools for disassembly and assembly
