Replacement Parts - 21
REPLACEMENT PARTS
Replacem ent Parts
Service Literature
If you would like a copy of the Parts Catalog or Technical
Manual for this machine call:
•
U.S. & Canada
: 1-800-522-7448.
•
All Other Regions
: Your John Deere dealer.
Parts
We recommend John Deere quality parts and lubricants,
available at your Authorized Service Center.
Part numbers may change, use part numbers listed below
when you order. If a number changes, your dealer will have
the latest number.
When you order parts, your Authorized Service Center
needs your machine serial number and engine serial
number. These are the numbers that you have recorded on
the inside front cover of this manual.
Touch-up paint is available in 340 grams (12 oz.) aerosol
cans. Scotts Orange (part number: TY24745) and Scotts
Grey (part number: TY 24747)
Part Numbers
(Part numbers are subject to change without notice. Part
Numbers may be different outside the U.S.A.)
ITEM PART NUMBER
Air Cleaner Element (Foam):
• S1642
• S1742
• S2046
M92360
LG272403S
LG273638
Air Cleaner Element (Paper):
• S1642
• S1742
• S2046
LG496894JD
LG496894JD
LG499486
Fuel Filter AM38708
Oil Filter AM125424
Battery TY21752
Spark Plug M78543 (Champion
RC12YC)
Fuse-15 amp 99M7065
Headlight Bulb AD2062R (GE-1156)
Ground Drive Belts:
• S1642
• S1742
• S2046
GX10851
GX10062
GX10644
Belts:
• 42-Inch Mower Drive Belt
• 46-Inch Mower Drive Belt
M124895
GX10176
Blades 42-Inch Deck:
• Standard
• Bagging
• Mulching
M139802 or M139803
M139803
M139802
Blades 46-Inch Deck:
• Standard
• Bagging
• Mulching
M127466
N/A
M119232
Leveling Gauge TY15272
