1.3.12 Safety guidelines for handling batteries
Never leave the battery close to a flame or fire.
Use only insulated tools.
Never use sulphuric acid or acid water to top up the electrolyte level.
Danger
2. General description
Figure A
Earth connection (no.1) MAX / ECO Mode (no. 9)
Inspection cover (no.2) Tank pressurisation pump (no.10)
Fuel tap (no.3) Indicator lamps (no.11)
Fuel tank aeration pointer (no.4)
A. Operating light
Fuel tank cap (no.5)
B. Overload indicator
Choke (no.6)
C. Oil safety indicator
Recoil starter (no.7) Spark plug access cover (no.12)
Electrical socket (no.8) Muffler (no.13)
Figure B
Inspection trap cover (no.1)
Oil filler and drain plug (no.2)
Maximum oil filling level
Figure C
Fuel tank aeration pointer RUN
/
/
S
S
T
T
A
A
R
R
T
T (no. 1) Fuel filter (no. 4)
Tank pressurisation pump (no.2)
Fuel strainer (no.3)
Maximum fuel filling level
Figure D
Air filter cover (no.1)
Filter element (no.2)
Filter element cleaning
Figure E
Spark plug access cover (no.1) Spark plug (no. 2)
3. Preparation before use
3.1. Positioning the generating set for operation
Choose a site that is clean, well ventilated and sheltered from bad weather.
Place the generating set on a flat, horizontal surface which is firm enough to prevent the set sinking down (under no circumstances
should the set tilt in any direction by more than 10°).
Store the additional supplies of oil and fuel within close proximity, whilst maintaining a certain distance for safety.
3.2. Earthing the generating set
The generating sets supply electrical current when in operation: risk of electrocution.
Connect the generating set to the ground at each use.
Dange
To connect the set to the ground: Attach a 10 mm
2
copper wire to the set’s earth connection and to a galvanised steel earthing rod
driven 1 meter into the ground.
3.3. Checking the oil level
Before starting the generating set, always check the level of engine oil.
Supplement it with the recommended oil (see § Specifications) with the help of a funnel, up to the upper limit of
the gauge.
Important
n Open the inspection cover (fig. A – no. 2).
o Unscrew the oil filler plug (fig. B – no. 2).
p Check the oil level.
q If necessary supplement it.
r Screw back the filler plug.
s Wipe any excess oil with a clean cloth.
t Close the inspection cover (fig. A – no. 2).
