SE Electronics RNR1 - RN17 Technical Specifications

9
Technical Specifications (RN17)
Capsule Type
Hand-Crafted True Condenser
Diaphragm
17.2mm Gold/Mylar
Polar pattern
Cardioid (omnidirectional capsule available separately)
Frequency range
20 Hz – 20 kHz
Sensitivity
5.96 mV/Pa (-44.5dB)
Max. SPL (0.5% THD @1kHz)
131 dB
Signal to noise ratio
76 dB
Self noise
18 dB(A) cardioid, 15 dB(A) omni
Power requirements
+48V phantom power
Electrical Impedance
200 Ohms
Matching Connectors
XLR3F
Diameter
44 mm (transformer), 17 mm (capsule)
Length
200 mm
Weight
320 g / 11.32 oz
Stereo Bar (Matched Stereo Pair Only)
Weight
245 g / 8.64 oz
Dimensions
300 x 25 mm
Max. width between mic mounts
276 mm
Min. width between mic mounts
58 mm
Frequency response Polar Pattern
