89
Carburetor-Equipped Models
TYPICAL
1. Engine drain hose
RFI Models
Disconnect the water supply hose used
to cool the magneto. It features a quick
connect fitting. Press both tabs and pull
fitting in order to disconnect hose.
This hose is located at the bottom of
the magneto cover beside the engine
support.
Wash the body with soap and water
solution (only use mild detergent).
Rinse thoroughly with fresh water. Re-
move marine organisms from the hull.
TYPICAL
1. Disconnect this hose
Water should flow out of the fitting
(magneto cooling circuit) and hose
(crankcase heat exchanger). Push and
hold hose against bilge so that draining
can take place.
TYPICAL
1. Fitting
2. Hose
Reconnect hose when done.
DI Models
Disconnect the quick connect fitting.
Press both tabs and pull fitting.
DISCONNECT THIS HOSE
Lower hose as necessary so that drain-
ing can take place.
Reconnect fitting when done.
Also ensure air compressor drain line
is not obstructed. Clean as necessary.
F07E0MY
1
F07E05Y
1
F07E06Z
2
1
F07E0HY
smo2001-003a.book Page 89 Wednesday, August 30, 2000 1:25 PM
