Sea-doo Spark Series User Manual

110
1. Self-tapping screws
15.Remove ten M6 nuts and screws
from both sides of central body.
1. Nuts and screws
16.Carefully lift the central body off
the hull using a lifting belt.
NNOOTTEE::
When lifting central body, wrap belt
around handlebars. Wrapping belt
elsewhere on central body to lift it may
cause damages.
CCeennttrraall BBooddyy IInnssttaallllaattiioonn
1. Properly place central body align-
ment tabs on hull.
CCEENNTTRRAALL BBOODDYY -- SSTTAARRBBOOAARRDD SSIIDDEE
VVIIEEWW
1. Grooved alignment tab on central body
2. Rib in hull
2. Install screws adjacent to align-
ment tabs first to ensure alignment
tabs remain properly engaged.
1. Screws adjacent to alignment tabs
3. Install two screws on rear support.
1. Screws on rear support
4. Install screws and tighten nuts on
both sides of central body to the
recommended torque.
1. Nuts and screws
TTiigghhtteenniinngg TToorrqquuee
M6 nuts
3.5 ± 0.5 Nm
(31 ± 4 lbf-in)
5. Install and tighten screws on front
and rear of central body to the rec-
ommended torque.
MAINTENANCE PROCEDURES

Sea-doo Spark Series Specifications

General

Displacement	899 cc
Hull Material	Polytec
Model	Spark, Spark Trixx
Engine Type	Rotax 900 ACE
Horsepower	60 hp / 90 hp
Fuel Type	Gasoline
Fuel Capacity	7.9 US gal (30 L)
Seating Capacity	2 or 3
Length	120 inches (305 cm)
Width	46 in (117 cm)
