- Fit the articulated arm into the motor shaft and lock it with the special screws (Fig. 13).
- The protection cover must be mounted on the end of all adjustments.
FLIPPER
Fig. 13
Fig. 14
21
For further information see point “External release”.
EXTERNAL RELEASE MOUNTING
ATTACHMENT OF THE ARTICULATED ARM TO THE MOTOR
FITTING AND CONNECTION INSTRUCTIONS
ENGLISH
Sistemi Elettronici
di Apertura Porte e Cancelli
International registered trademark n. 804888
®
Return spring
