Seabreeze STS11 - Page 6

10
Fig. 1. Touchscreen Thermostat dimensions in inches. (mm).
STS11 Touchscreen Pro
g
rammable Thermostat
5.98 in.(152mm)
4.48in. (114mm)
1.235 in.(30.60mm)
11
Fig. 2. Touchscreen Thermostat Back Case dimensions in inches. (mm).
STS11 Touchscreen Pro
g
rammable Thermostat
1.51 in.(38.5mm) 0.84 in .(21.5mm)
1.77 in.(45mm)
1.67 in.(42.5mm)
