1. Introduction
2. Features
☆ HDMI 2.0b, HDCP 2.2 and HDCP 1.4 compliant
☆ Up to 4K2K@60Hz (4:4:4) on all HDMI and HDBaseT ports
☆ Supports pass-through audio up to 7.1 channels of High Definition audio
(LPCM, Dolby TrueHD, and DTS-HD Master Audio)
☆ Digital and analog audio extractor from any one of outputs (Configurable)
☆ HDR and smart EDID management supported
☆ 24V POC on all HDBaseT ports
☆ Control is via on-panel Button, IR, RS-232, LAN and Web UI
☆ 1U rack mounted design size
3. Package Contents
The HDBaseT™ 8x8 Matrix Switcher supports the transmission of video (up
to 4K2K@60Hz YUV4:4:4, 8-bit, 18Gbps, HDCP 2.2) and multi-channel
digital audio such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and
DTS-HD Master audio from 8 HDMI sources to 6 HDBaseT™ outputs and
2 independent HDMI outputs. The HDBaseT™ outputs allow transmission
of video, audio and control via a single CAT6/6a cable up to 230ft/70m. The
matrix can be controlled via front panel button, IR remote control, RS-232,
TCP/IP or Web GUI.
1/12
① 1x HDBaseT™ 8×8 Matrix Switcher
② 6x HDBT Receivers
③ 1x IR Remote Control (Matrix)
④ 1x RS-232 serial cable
⑤ 7x Phoenix connectors
⑥ 1x 100~240V AC 50/60Hz Power Cable
⑦ 16x Wideband IR receiver cables
⑧ 15x Wideband IR blaster cables
⑨ 12x Mounting Ears (Receiver)
⑩ 2x Mounting Ears (Matrix)
11
1x User Manual
Website: www.seada.co.uk E-mail: sales@seada.co.uk
