4–TEC SC Models UNCRATING
UNCRATING
Crate Cover
1
22
F00A2A6
Carefully lay the crate on its bottom.
CAUTION: Allowing the crate to drop may cause
serious damage to the watercraft.
Using a drill or a screwdriver, remove all screws
[
[[
[1]
]]
] retaining crate cover to crate base.
Assisted by another person, lift up crate cover [
[[
[2]
]]
].
N
NN
NO
OO
OT
TT
TE
EE
E:
::
: Do not tip cover toward the front or back of
the watercraft. Raise cover vertically [
[[
[2]
]]
]fromboth
ends at the same time.
Remove parts from the watercraft’s rear storage
compartment.
Lifting the watercraft
1
32
F08A056
Cut strapping at watercraft front eyelet.
Release [
[[
[1]
]]
] the shipping bracket [
[[
[2]
]]
] at the rear of
the watercraft from the crate base [
[[
[3]
]]
].
Lift the watercraft using the appropriate lift kit and
install it on a proper support.
Shipping Bracket
1 32
F08A066
Remove the shipping bracket [
[[
[1]
]]
] from the venturi.
Discard the shipping bracket and the hexagonal
bolts [
[[
[2]
]]
].
Keep the flat washers [
[[
[3]
]]
].
Predelivery 2004-1 3 / 15
