Seaflo COMPACT SFMTM-01 - Servicing - Testing

5. SERVICING - TESTING
REFER to the OPERATING INSTRUCTIONS and follow the procedure for "2. Normal use".
If the flushing pump is hard to prime, half-fill the bowl with fresh water.
ON COMPLETION OF SERVICING
SHUT ( ) THE FLUSH CONTROL
CLOSE BOTH SEACOCKS.
COMPACT (SFMTM-01)
14
page
13
page
225.0mm(8.86")
110.0mm(4.33")
55.0mm(2.16")
71.5mm(2.81")
4-8.8mm(0.35")∅
X-X SECTION VIEW
(display base mounng hole)
450.0mm（17.72″）
331.5mm(17.72″)
415.0mm(16.34″)
Seat, lid & hinge set
Ceramic bowl
Hinge set
Cap
Bolt assembly
Base valve gasket
Toilet seal
O-ring (plug)
Plug seal
Base plug
Intake seal
Intake elbow
1
2
3
4
5
6
7
8
9
10
11
12
Hose
Discharge flange
Joker valve
Discharge elbow
Self-tapping screws
Pump cylinder
Top valve seat
Valve block fastening washer
Top valve gasket
Copper valve block
Screw(flush lever)
Flush control lever
13
14
15
16
17
18
19
20
21
22
23
24
O-ring (flush lever)
Cam
spring
Pump piston
Piston seal
Screw (valve cover)
Pump cover
Seals
Screw cap seal
Screw cap
Buffer
Handle
25
26
27
28
29
30
31
32
33
34
35
36
2
3
4
5
6
7
8
9
10
1
11
12
13
14
15
16
17
18
19
20
21
22
23
24
2526
27
28
29
30
31
32
33
34
35
36
DIMENSIONAL DRAWING
EXPLODED VIEW
