Seaflo COMPACT SFMTM-01 - Section View

REGULAR (SFMTM-01-R)
(display base mounng hole)
X-X SECTION VIEW
225.0mm(8.86″)
110.0mm(4.33″)
55.0mm(2.16″)
71.5mm(2.81″)
4-8.8mm(0.35″)∅
482.0mm（18.98"）463.0mm（18.24"）
334.8mm（13.18"）
Seat, lid & hinge set
Ceramic bowl
Cap
Bolt assembly
Base valve gasket
Toilet seal
O-ring (plug)
Plug seal
Base plug
Intake seal
Intake elbow
Hose
1
2
3
4
5
6
7
8
9
10
11
12
Discharge flange
Joker valve
Discharge elbow
Self-tapping screws
Pump cylinder
Top valve seat
Valve block fastening washer
Top valve gasket
Copper valve block
Screw(flush lever)
Flush control lever
O-ring (flush lever)
13
14
15
16
17
18
19
20
21
22
23
24
Cam
spring
Pump piston
Piston seal
Screw (valve cover)
Pump cover
Seals
Screw cap seal
Screw cap
Buffer
Handle
25
26
27
28
29
30
31
32
33
34
35
36
4
5
6
7
8
9
10
1
1112
13
14
15
16
17
18
19
20
21
22
23
24
2526
27
28
29
30
31
32
33
34
35
2
3
16
page
15
page
DIMENSIONAL DRAWING
EXPLODED VIEW
