Seagull Models Mitchell B-25 - Page 29

29
Locate the items neccessary to install
the electric power conversion included
with your model.
Recommend the items necessary to in-
stall the electric power conversion parts
included with your model.
ELECTRIC POWER CONVERSION
Attach the electric motor box to the re-
wall suitable with the cross lines drawn
on the electric motor box and rewall.
Using epoxy and balsa stick to secure the
motor box to the rewall. Please see pic-
tures below.
1.
2.
- Motor: 110 - 2000 Watts
- Propeller: 17x8 ~ 19x10
- ESC: 85A
- 8S- 9S Lipo
Attach the motor to the front of the
electric motor box using four 4mm blind
nut, four M4x25 mm hex head bolts to se-
cure the motor. Please see picture shown.
M4x25mm and washers
3.
4.
5.
