33
1.
STABILIZER SET INSTALLTION
ELEVATOR INSTALLTION SERVO
30.
Please see below pictures.
2.
3.
4.
Minimum servo spec.
Torque : 194 oz-in (14 kg-cm) @ 6.0V;
236 oz-in ( 17kg-cm) @ 7.4V
5.
