SERVO GEAR INSTALLATION
BOMB BAY DOOR SYSTEM
INSTALLATION
Minimum servo spec.
Torque : 91.65 oz-in (6.6 kg-cm) @ 4.8V;
113.87 oz-in (8.2 kg-cm) @ 6.0V
