Aircraft Maintenance Manual - Seamax M-22
SW / FW
Page 56
4.3.3.2 Materials required
Fluid for brake system, (not braking fluid)
Loctite 277
Nylon ¼ high pressure tubing
4.3.3.3 Type of maintenance
Line Heavy
4.3.3.4 Level of certification
Manufacturer/MMA/RS
Light Sport aircraft Repairman Maintenance Aircraft (LSRMA)
4.3.3.5 General
The Seamax M-22 braking system consists of two independent hydraulic lines; one for the right
wheel, and other for the left wheel. It is a differential brake system which allows you to make turns
with the airplane on ground.
The brake pedals and toe brakes can be controlled by both the pilot and passenger.
The brake system has two brakes cylinders for each wheel. These can also be controlled by both
the pilot and the passenger.
The oil tank feeds both hydraulic lines, and it is located behind the panel in the middle of the
cockpit.
