6
SeaStar Solutions
SYSTEM SET-UP QUICK
REFERENCE GUIDE
Filling and Purging Procedure
• Power Purge users. Refer to page 9 of this manual
.
• Manual filling and Purging users. Refer to page 8 of this
manual
.
• SeaStar Power Assist users.
Alignment Procedures
• Outboard installations refer to page 13 of this manual.
• Stern Drive installations refer to page 13 of this manual
.
• Inboard installations refer to page 13 of this manual
.
System Installation
• Install SeaStar Helm pump onto the dash using installation
instructions provided with your helm pump.
• Install steering cylinders using the installation instructions
provided with your steering cylinders.
• Install Liquid Alignment Valve (Liquid Tiebar) in a position that
allows easy access, but will not allow accidental turning of the
valve hand lever.
• Install your hose/tube as detailed in the following pages.
Be sure to plumb the system as per YOUR steering
system as several different systems are noted.
NOTICE
CYLINDER
CYLINDER
ALIGNMENT VALVE
HELM
STEP 1
System Pressure Test
• ALL users refer to page 13 of this manual to confirm safe and
proper operation of your steering system.
STEP 4
STEP 2
STEP 3
Oil level and System check is critical to the safe operation of your
boat, failure to follow this important step may lead to loss of steering
control resulting in property damage, personal injury and/or death.
WARNING
To Next Page
