Seat Leon - Page 134

Operation
Storing the retractable shelf
3 Valid for: Leon Sportstourer
Fig. 114
In the luggage compartment: space
t
o st
or
e the retractable shelf.
Fig. 115 In the luggage compartment: space
t
o st
or
e the retractable shelf.
The retractable shelf can be stored under the
luggage compartment v
ariabl
e fl
oor.
●
Remove the left and right covers
›››
Fig. 114
A
.
●
Pr
ess the head of the r
etr
actable shelf in
the direction of the arrow until it engages in
its housing
›››
Fig. 115.
●
Put the left and right covers in their original
position.
Variable luggage compartment
floor
Fig. 116 Variable luggage compartment floor:

r
aised position;

l
o
wered position.
Fig. 117 Variable luggage compartment floor:
inclined position.
Variable floor in high position
●
To move from the low position to the high
position, lift the fl
oor using the handl
e
›
››
Fig. 116
1
, and pull it back until the front
of the fl
oor has fully passed the supports
2
.
●
Move the floor forward over the supports as
f
ar as the r
ear seat backr
est and then lower
the floor with the handle
1
.
V
ariabl
e fl
oor in low position
●
To move from the high position to the low
position, lift the floor using the handle
›››
Fig. 116
1
, and pull it back until the front
of the fl
oor has fully passed the supports
2
.
●
Now let the front part fall to the floor and
slide the fl
oor f
orw
ards as far as the rear seat
backrest; lower the floor at the same time
with the handle
1
.
