SEC Sentry 822 PS - Page 14

14
Figure #2
Charger Fuse
Main Fuse
F1
F2
SIDE VIEW
Figure #1
ON/OFF
Inverter
TOP VIEW
POWER OUTPUT
Active When Lit
Charged = ON
Replace Battery
Charging = Flashing
BATTERY MONITOR
ALL Battery Indicators Are OFF
When Utility AC is Down
