Replacement
seca 674, 675
08.02.2013/MRE Seite 6 (9) 30-34-00-859_E1
When assembling the load cells (G, Fig. 3), the tightening torque for the four
cheese head screws (J, Fig. 3) of M
t
= 12.5 Nm must be observed.
Figure 3: Replacing the load cell
J
K
G
I
