9 Technical Data
Model C30III C60III C120III
Type Desktop unit Unit including
stand-up base
and LAPOS
Unit including stand-
up base and LAPOS
Max. medium width 415mm 720mm 1300mm
Max. cutting width 305mm 610mm 1220mm
Connections RS232C, USB
Display Back-lighted, 4-line LCD display
Plotter languages HP-GL, DMPL
Memory Unit has 1MB internal memory
Max. speed 600mm/s
Max. medium thickness 1mm
Contact pressure 50g – 500g
Mechanical resolution 0.025mm
Repetition accuracy < ± 0.1mm
Power supply 90V AC – 240V AC/ 50Hz – 60Hz
Ambient conditions + 5C - +35C / 30% - 70% humidity
Weight without packing 9kg 12kg 18kg
Weight with packing 11kg 16kg 39kg
Dimensions (W x H x D)
585mm x 265mm x
270mm
890mm x 265mm x
270mm
1465mm x 265mm
x 270mm
