4.3 Control Panel
a) Online-/Offline button
b) Test button (blade test)
c) LCD display
d) Arrow keys for control of cutting head and for pulling in vinyl
e) Zero point button
f) Pause button (to interrupt plotting operation)
g) Repeat button for repeating a job
h) Menu button for appliance settings
d
c
b
a
h
g
f
e
