7 Installation
7.1 Installing the device
The device does not generate system messages, error messages or fault messages.
Warning! Be sure to fix the device by fastening the screws (if it will be mounted on
machine).
Warning! It’s forbidden to install the device on wall.
In order to install the device, make sure that the incoming electrical power supply
complies with the following values:
Power supply
Only power supplies certified for the target market and
complying with the regulations in force for this specific
application must be used.
+ 12 V DC
Maximum electrical current deliverables
to the device = 5 A
Minimum power required 20 W
To install the device properly on machine, follow the procedure below:
1
Make sure the electric connection on the destination machine is off and the electric
power supply is disconnected from the device;
2
Prepare the machine /sheet/other making 4 holes of 4mm each, spaced according
to the hole spacing;
3
Fix device to the machine, using 4 screws that will be screwed in matching holes
in the plate with the 4 holes made in step 2;
4
Proceed to connect the electric supply to the device. Once inserted, turn the
connector clockwise in order to lock it in place;
5
Proceed to electrically connect the destination machine.
