Seco SYS-C31-DMV - Software Specifications

SYS-C31-DMV
Information subject to change. Please visit www.seco.com to find the latest version of this manual.
Page.6 of 23
3 Technical specifications
3.1 SYS-C31-DMV device hardware specifications
The table below features the board hardware specifications:
Processor
CPU Rockchip RK3399K (2x Cortex-A72 + 4x Cortex-A53)
Mass Storage
2GB LPDDR4 RAM
16GB eMMC
RTC
Network connection
IEEE 802.11 ac/a/b/g/n WLAN
Bluetooth 5.0
LTE Cat 4 with internal LTE modem’s SIM holder
LTE 2nd antenna connector for DIVERSITY mode is available
(Don't connect anything here; it invalidate the certification)
RJ45 Ports x2 for Ethernet LAN connection
Peripherals to be
supported
USB2.0 (x3)
USB3.0
USB type-C
HDMI
RJ45 (x2)
RS232 on D-SUB DB9 MALE (x2)
Video
1x HDMI
1x DP (USB 3.0 Type-C alternate mode)
Operating System
Android 11
Type of installation
Fastening for integration use on industrial machine using
threaded pins directly on the mechanical plate.
Power Supply
Nominal: 12 VDC with 2,5mm jack with lock
Battery model
CR2032 (internal battery not replaceable)
Operating
temperature in user
environment
-20°C/+70°C **
Exposed to limit areas of 2000 m a.s.l.
Humidity
0~95% @40°C non-condensing
