password zebra!password
In these examples,! denotes a descriptive comment # indicates a configuration line that is
currently commented out, which you may want to uncomment depending on your network
setup.
In zebra.conf, enter:
! Uncomment and set telnet/vty passwords to enable telnet
access on port 2601
#password changeme
#enable password changeme
! Uncomment no multicast if you dont wan’t to accept or send
multicast rip packets for the specified interface
#interface eth0
#no multicast
#interface eth2
#no multicast
In ripd.conf, enter:
! Uncomment and set telnet/vty passwords to enable telnet
access on port 2602
#password changeme
#enable password changeme
! RIP version 2 authentication
#interface eth0
#ip rip authentication mode text
#ip rip authentication string snapgear
! Enable the RIP routing process
router rip
! Define interfaces which exchange RIP messages over
network eth0
108
