SEDEMAC GC1200 User Manual

GC1100 SEDEMAC
Page | 24
Level 0
Level 1 (On
screen)
Level 2 (On screen) *
Parameters (On screen)
(LOP/DIG F)
(SENSOR SELECTION)
Anlg In LOP
(Digital) Source
((DIG) SOURCE)
Refer Table 21
(Digital) Polarity
((DIG) POLARITY)
Close to Activate/Open to
Activate
(Digital) Action
((DIG) ACTION)
None/Notification/Warning
/Electrical Trip/Shutdown
(Digital) Activation
((DIG) ACTIVATION)
Never/From Engine Start/
From Monitoring On/Always
(Digital) Activation Delay
((DIG) ACTIVATION DELAY)
1 – 60 sec
(LOP) Low Level Shutdown
(SHUTDOWN)
Disable/Enable
(LOP) Low Level Shutdown
Threshold
(SHUTDOWN THRESHOLD)
0.0 – 9.8 bar
(LOP) Low Level Warning
(WARNING)
Disable/Enable
(LOP) Low Level Warning
Threshold
(WARNING THRESHOLD)
0.2 – 10.0 bar
(LOP) Circuit Fault Action
(OPEN CKT ACTION)
None/Notification/Warning/
Electrical Trip/Shutdown
(LOP) Lube Oil Pressure Sensor
Calibration Table
Refer Table 24
Analog Input 4
(LOP/DIG I)
Use Input As
(SENSOR SELECTION)
Not used/Digital Input F/
Anlg In LOP (4-20mA)
(Digital) Source
((DIG) SOURCE)
Refer Table 21
(Digital) Polarity
((DIG) POLARITY)
Close to Activate/Open to
Activate
(Digital) Action
((DIG) ACTION)
None/Notification/Warning
/Electrical Trip/Shutdown
(Digital) Activation
((DIG) ACTIVATION)
Never/From Engine Start/
From Monitoring On/Always
(Digital) Activation Delay
((DIG) ACTIVATION DELAY)
1 – 60 sec
(LOP) Low Level Shutdown
(SHUTDOWN)
Disable/Enable
(LOP) Low Level Shutdown
Threshold
(SHUTDOWN THRESHOLD)
0.0 – 9.8 bar
(LOP) Low Level Warning
(WARNING)
Disable/Enable
(LOP) Low Level Warning
Threshold
0.2 – 10.0 bar

SEDEMAC GC1200 Specifications

General

Brand	SEDEMAC
Model	GC1200
Category	Controller
Language	English
