Intended use
This appliance is suitable for gardening pruning, bush pruning, small
branch pruning, wood cutting, widely used in gardens, parks, farms,
highways, pastures, orchards, greenhouses. Any other uses or
modifications to the machine are deemed to be improper usage and may
result in serious physical injury. The manufacturer accepts no
responsibility for damage(s) attributable to misuse.
Only insert the rechargeable battery once the 1 device
is completely assembled.
If the device is switched on accidentally, there is a 1
danger of injury.
Taking the installation of CH600 as an example, the installation methods
of other models are the same.
Model
Rated voltage
21V
Battery capacity
Standard battery
cartridge
Net weight
(with battery)
Sprocket
Chain speed
Pith
Number
of teeth
Chain oil tank
volume
Standard guide
bar length
Input voltage
Single - phase AC
1.32 kg
(2.91Ibs)
1.82 kg
(4.01Ibs)
1.47 kg
(3.24Ibs)
1.85 kg
(4.07Ibs)
152.4 mm
(6″)
1/4″
5m/s
8m/s
30ml
152.4 mm
(6″)
203.2 mm
(8″)
203.2 mm
(8″)
2000 mAh 4000 mAh 2000 mAh 2000 mAh
Protective Baffle
Oil Tank
Chain
Guide Plate
1. Loosen the nut and remove
the side cover
2. Put the chain into the guide
plate
Power Switch
Safety Button
Battery Pack
Oiler Button
Charging time
2-3 hours 3-4 hours 2-3 hours 2-3 hours
Working time
15-25 min
Input frequency
50/60 Hz
18
22
100-240 V
30-40 min 15-25 min 15-25 min
SE2000F,SE2000D, SE4000T,SE4000D
CH600 CH600+ CH800 CH810
Technical specifications
Replacing & installing the chain
Product Information
Assembly
-05-
-06-
