Ensure that the exterior of the battery is clean and dry
before connecting to the charger or machine.
1. Loosen oil tank cap
Adding lubricant oil
Installing the Battery into the Mini Chainsaw
Removing the battery from the mini chainsaw
2. Pour the bar oil into the oil
tank. Max.30ml (bar oil is
notincluded)
Tips: It is not recommended
to fill the tank too full
Insert the battery into the base of the machine
as shown in the picture. Push the battery further
forward until it clicks intoplace.
(Battery: Pay attention to align the slots and
inserts.)
Push the battery unlock button.
Pull the battery out of the Chainsaw.
Note: The regular chain & bar oil is applicable for mini chainsaw.
Charging the battery with the charger
Do not expose the battery to extreme conditions such as high
temperature or shock. Otherwise, it will cause personal injury due to the
leakage of the electrolytic solution.
Before charging, check that the surface of the battery is cleanand dry.
Before using for the first time, the battery needs to be fully charged.
After the battery is fully charged remove the charger plug from the
outlet and remove the battery from the charger.
3. Tighten oil tank cap
4. Press the oiler button to oil
the chain.
Tips: Let the chain rotate after
pressing to evenly distribute
the oil
Charging jack
Indicator Light
Red
Green
Status
Charging
Charging completed
-09-
-10-
Precautions of battery charging
