Switch off in Aircraft –Follow any restrictions. Wireless devices can cause interference
in aircraft.
Switch off when refueling
–
Do not use Track when at a refueling point. Do not use near
fuels or chemicals.
Water Resistance –Track is not water resistant. Keep it dry. Use waterproof bag if
necessary.
3 Track Parameters& Panel Description
Item Specification
Charging Voltage DC 5V/500mA (Micro USB port)
Internal Battery Rechargeable and removable 830 mAh battery (3.7V)
Operating temperature -20° to 55° C
Humidity 5% to 95% Non-condensing
GSM module GSM 900/1800/1900Mhz
GPS Chipset latest GPS (AGPS)
GPS Sensitivity -158Db
GPS Frequency L1, 1575.42 MHz
C/A Code 1.023 MHz chip rate
Channels 20 channel all-in-view tracking
Position Accuracy 10 meters, 2D RMS
Velocity Accuracy 0.1 m/s
Time Accuracy 1 us synchronized to GPS time
Default datum WGS-84
Reacquisition 0.1 sec., average
Hot start 1 sec., average
Warm start 38 sec., average
Cold start 42 sec., average
Altitude Limit 18,000 meters (60,000 feet) max.
Velocity Limit 515 meters/second (1000 knots) max.
Acceleration Limit Less than 4g
Jerk Limit 20 m/sec
