20
3.7.4. COIN HANDLING INSTALLATION
· Only QUALIFIED SERVICE PERSONNEL should carry out this operation.
When fitting the coin mechanism to the door please refer to the specific manufacturers installation
instructions for that coin mechanism. To fit the door to the machine follow the procedure below.
· Loosen all of the bolts on the frame that secure the clips.
· Turn all clips in towards the door.
·
Position the door into the aperture in the machine.
·
Turn the clips around so that they will hold the door in the
machine.
·
Tighten all of the bolts.
NOTE: DOUBLE FRAMED MINI DOOR SHOWN. SINGLE
FRAMED DOOR SIMILAR FITTMENT.
