Troubleshooting
No picture and sound:
• Is the TV or monitor turned ON?
• Are the AC Adaptors connected to the Genesis
32X, Genesis and Sega CD?
• Are the AC Adaptors plugged into electrical
outlets?
• Are the Genesis 32X and Sega CD firmly
connected to the Genesis?
• Is the Genesis Power Button turned ON?
• Are all cable connections secure?
• Is the TV tuned to the appropriate channel ?
• Is the TV system switch on the RF Unit in the
current position?
• Is the game cartridge firmly inserted in the
Genesis 32X cartridge slot with the label facing
forward?
• If connecting through the VCR -- is the VCR
turned ON?
• If connecting through the VCR -- is the VCR set to
receive line input?
Sega CD logo does not appear when the Sega CD or
Sega CD 32X disc is Inserted:
• Is the game cartridge removed from the cartridge
slot on the Genesis 32X?
Screen flickers or no color:
• Are the TVchannel fine adjustments set properly?
• Are the TV color controls set properly?
No game sound:
• Is the TV volume too low or OFF?
• Have the connection cables come loose or been
disconnected?
• Is the power switch on the audio system turned
ON?
No picture:
• Are the Connector Cable and the Conversion
Cable connected to the correct AV Jacks on the
back of the Genesis 32X?
If you continue to have a problem. follow the
instructions in this manual and carefully reconnect
your Genesis 32X system. If the problem persists,
please call the Sega Consumer Service Department at
1-800·USA-SEGA
Genesis 32X Hardware Information
Physical Characteristics
Power Usage Genesis 32X AC Adaptor
(DC 10V)
Elec. Consumption: Approx. 4W
Usage Environment: Temperature 5C to 35C
Humidity 20% to 80% RH
Exterior Measurements: Width 115 mm
Length 210 mm
Height 100 mm
Specifications
CPU: SH2 (23MHz) x 2
RAM: 2Mbit
Video RAM: 2Mbit
VDP: Custom LSI, NTSC
standard, 32,768 colors
Video output:: Video/RF/RGB
Sound Circuitry: PWM sound source
Slot: Cartridge : Slot
Note: Characteristics and specifications are subject to
change.
