Sega SpongeBob SQUAREPANTS - Page 34

26
www.seuservice.com
Rear Game Area
15
14
13
12
11
5
6
7
8
9
10
2
1
ITEM NO. PART NO. DESCRIPTION NOTE
1 999=2275 Rear Handles HAPP
2 998-0224 Assy Oscillating Light
5 998-0221 PCBoard MPU
6 998-0223 3 Digit LED Display
7 998-0228 5V Dummy Load
8 998-0220 Power Supply
9 999-2157 PCB Bracket
10 999-2276 Motor Mounting Bracket
11 999-2284 Motor, 9RMPM 120VAC
12 999-2277 Flipper Bushing
13 999-2278 Motor Hub
14 999-2279 Motor Link
15 999-2280 Motor Shaft
11
15
14
13
12
